Product: Eaton Moeller series NZM Undervoltage release
Description: Eaton Moeller series NZM Undervoltage release, 110-130VDC, for NZM1, L
📋 Detailed Specifications
| Parameter | Value |
|---|---|
| Model Code | NZM1-XUL110-130DC |
| Catalog Number | 259487 |
| Global Catalog | 259487 |
| EAN / GTIN-13 | 4015082594879 |
| Length | 37.0 mm |
| Height | 66.0 mm |
| Width | 32.0 mm |
| Weight | 0.044 kg |
| Special Features | Non-delayed disconnection of NZM circuit-breaker or N switch-disconnector when the control voltage sinks below 35 – 70% US. | For use with emergency-stop devices in connection with an emergency-stop button. | When the under-voltage trip is switched off, accidental contact with the circuit breaker’s primary contacts is prevented when switched on. | Undervoltage releases cannot be installed simultaneously with NZM…-XHIV… early-make auxiliary contact or NZM…-XA… shunt release. |
| Compliances | UL/CSA | IEC | RoHS conform |
| Certifications | UL (File No. E140305) | UL (Category Control Number DIHS) | CE marking | UL listed | CSA (Class No. 1437-01) | IEC60947 | CSA certified | CSA (File No. 22086) | CSA-C22.2 No. 5-09 | UL489 |
📄 Specifications are sourced from official manufacturer datasheets and are provided for reference only.
For the latest official information and pricing, please contact us for an authoritative quotation.
