Product: Eaton Moeller series NZM Earth leakage relay
Description: Eaton Moeller series NZM Earth-fault release, 300mA, 4p, bottom
📋 Detailed Specifications
| Parameter | Value |
|---|---|
| Model Code | NZM1-4-XFI300U |
| Catalog Number | 104613 |
| Global Catalog | 104613 |
| EAN / GTIN-13 | 4015081044238 |
| Length | 180.0 mm |
| Height | 80.0 mm |
| Width | 120.0 mm |
| Weight | 0.9 kg |
| Voltage Rating (AC) | 200 – 415 V AC, min. 80 V AC for detection of fault currents type A/AC (dependent on mains voltage) |
| Number of Poles | Four-pole |
| Degree of Protection | IP20 (operating component area) |
| Mechanical Lifespan | 20000 operations |
| Ambient Temp — min | -5 °C |
| Ambient Temp — max | 40 °C |
| Mounting Method | Bottom |
| Application | In three-phase systems |
| Special Features | Earth-fault release to IEC/EN 60947-2not UL/CSA approvedSuitable for use in three-phase systemsPulse-current sensitive type A according to core-balance principleFor 4 pole NZM1-4 circuit-breakers and N1-4 switch-disconnectorsSupply voltage-dependent Ue = 200 – 415 V 50/60 HzControl knobs, sealable.Bottom mounting up to 100 A |
| Compliances | IEC RoHS conform |
| Certifications | IEC/EN 60947-2 IEC/EN 60947-2 annex B |
📄 Specifications are sourced from official manufacturer datasheets and are provided for reference only.
For the latest official information and pricing, please contact us for an authoritative quotation.
