Product: Eaton Moeller series NZM Undervoltage release
Description: Eaton Moeller series NZM Undervoltage release, 380-440VAC, +2early N/O, for NZM4, 20
📋 Detailed Specifications
| Parameter | Value |
|---|---|
| Model Code | NZM4-XUHIV20380-440AC |
| Catalog Number | 266249 |
| Global Catalog | 266249 |
| EAN / GTIN-13 | 4015082662493 |
| Length | 107.0 mm |
| Height | 51.0 mm |
| Width | 64.0 mm |
| Weight | 0.24 kg |
| Special Features | Undervoltage release with 2 early-make auxiliary contacts, e.g., for early-make connection of undervoltage release in main switch applications, as well as for interlock and load shedding circuits. | For use with emergency-stop devices in connection with an emergency-stop button. | When the under-voltage trip is switched off, accidental contact with the circuit breaker’s primary contacts is prevented when switched on. | Early-make of auxiliary contacts on switching on (manual operation): approx. 90 ms. | Cannot be used in conjunction with NZM…-XR… remote operator. |
| Compliances | IEC | UL/CSA | RoHS conform |
| Certifications | IEC60947 | CE marking | UL489 | UL (File No. E140305) | CSA (Class No. 1437-01) | UL listed | UL (Category Control Number DIHS) | CSA (File No. 22086) | CSA certified | CSA-C22.2 No. 5-09 |
📄 Specifications are sourced from official manufacturer datasheets and are provided for reference only.
For the latest official information and pricing, please contact us for an authoritative quotation.
